ADTi GF-270 2 Axis Fixed-Wing Mapping Camera Gimbal

The ADTi GF-270 is a compact 2-axis ortho-mapping gimbal for small and medium fixed-wing and VTOL survey aircraft. It carries ADTi's 20/24MP, 36MP, 42MP and 61MP mapping cameras on two axes, so the camera can be held level through the aircraft's bank and pitch for consistent photogrammetry frames.

Key features

• 205 g gimbal with an 800 g payload limit, light on the airframe while leaving room for ADTi's heavier high-resolution cameras.
• Carbon fibre, 3D-printed nylon and aluminium build running on metal bearings.
• PWM control input, so it can be driven from the autopilot or a spare receiver channel.
• 14 × 13 × 4 cm envelope sized for slim fixed-wing fuselage bays.

Specifications

• Model: GF-270
• Axes: 2
• Weight: 205 g
• Maximum payload: 800 g
• Dimensions: 14 × 13 × 4 cm
• Materials: carbon fibre, 3D-printed nylon frame, aluminium mount
• Bearings: metal
• Control input: PWM
• Stabilisation: supported (optional)
• Compatible cameras: ADTi 20/24MP, 36MP, 42MP, 61MP

The GF-270 is designed around ADTi cameras, so check your camera model against the supported list before ordering and confirm the payload bay clears the 14 × 13 × 4 cm envelope.
