Gremsy Pixy MR 3-Axis Mapping Gimbal

The Gremsy Pixy MR is a commercial-grade, 3-axis mapping gimbal purpose-built for the Sony a7R IV and a7R V cameras. Engineered for professional photogrammetry, surveying, and aerial inspection, it integrates seamlessly into heavy-lift drones and commercial platforms running Pixhawk or DJI M300 RTK architectures. By locking in support for a specific high-resolution camera series, the Pixy MR eliminates balancing guesswork and provides a ready-to-deploy mapping solution.

Key features

• Optimised exclusively for Sony a7R IV and a7R V cameras with select lightweight mapping lenses

• Deep flight controller integration via MAVLink (Pixhawk/Cube) and DJI M300 RTK systems

• Continuous 360-degree pan rotation via a built-in slip ring for unrestricted aerial mapping

• Gremsy quick-release mechanism for rapid payload deployment and field swaps

• Integrated wiring for camera power and trigger control directly through the gimbal

Specifications

• Axis: 3-axis (Pitch, Roll, Pan)

• Weight: 650 g

• Input voltage: 14–52 V

• Camera compatibility: Sony a7R IV, a7R V

• Supported telemetry: MAVLink, DJI M300

• Interfaces: USB, UART, CAN, S.Bus

This gimbal is designed strictly for commercial operations. Ensure your heavy-lift drone can supply the required voltage range and has an appropriate mounting hardpoint for the quick-release plate before integrating.
