SIYI ZR30 4K 30x Optical Zoom 3-Axis Gimbal Camera

The SIYI ZR30 is an enterprise-grade 3-axis gimbal camera designed for inspection, surveillance, and heavy-lift UAVs. Built around a 1/2.7-inch Sony CMOS sensor, it delivers clear 4K footage and handles extreme long-range visual tasks through its powerful 30x optical zoom mechanism.

Key features

• Massive reach: combines a 30x optical zoom with up to 180x hybrid zoom for precise detail retrieval at safe standoff distances.
• High-resolution imaging: captures 4K video and 8 MP effective-resolution stills with excellent low-light performance.
• Advanced stabilisation: a brushless 3-axis gimbal ensures rock-solid tracking and footage retention during aggressive flight manoeuvres or high winds.
• Flexible integration: interfaces seamlessly with commercial flight controllers via S.Bus, UART, and Ethernet (UDP/TCP).

Specifications

• Sensor: 1/2.7" Sony CMOS (8 MP effective)
• Video resolution: 4K @ 25 fps, 1080p @ 30 fps
• Zoom: 30x optical, 180x hybrid
• Input voltage: 11-25.2 V (3-6S)
• Control interfaces: S.Bus, UART, UDP, TCP
• Video output: Ethernet, Micro-HDMI
• Weight: 628 g (including quick-release board)
• Dimensions: 132 x 100 x 159 mm (including quick-release board)
• Focal length: 4.5-148.4 mm, F1.3-F2.8
• Gimbal range: pitch -90 to +25 degrees, yaw +/-270 degrees, roll +/-45 degrees
• Power consumption: 5 W average, 12 W peak
• Storage: microSD, up to 128 GB

Fully compatible with ArduPilot and PX4 ecosystems, the ZR30 is an ideal payload for search-and-rescue, power line inspection, and agricultural monitoring platforms.
