Apex DC HD 5" FPV Frame Kit

The Apex DC HD 5-inch frame kit modifies the legendary Apex geometry into a Deadcat (DC) layout, designed specifically to keep propellers out of your high-definition flight footage. By sweeping the front arms back and out, it maintains the locked-in freestyle flight characteristics of the original while providing a completely unobstructed view for modern HD video systems like the DJI O3, Caddx Vista, and Walksnail Avatar.

Key features

• Deadcat geometry ensures a clear, prop-free HD camera view for cinematic recording

• Heavy-duty 5.5mm carbon fibre arms reduce resonance and withstand hard crashes

• Dual stack mounting accommodates both 20x20mm and 30.5x30.5mm flight electronics

• Dedicated 20x20mm rear mounting specifically positioned for digital video transmitters

• Custom aluminium camera plates provide rigid protection for 19mm and 20mm FPV cameras

Specifications

• Geometry: Deadcat (DC)

• Wheelbase: 225 mm

• Arm thickness: 5.5 mm

• Plate thickness: 2.5 mm (Bottom / Main), 2 mm (Top)

• FC / ESC mounting: 20x20, 30.5x30.5

• VTX mounting: 20x20

• Motor mounting: 16x16 mm

• Camera fit: 19 mm, 20 mm

This frame is an excellent foundation for builders who demand aggressive freestyle performance without sacrificing their onboard footage to spinning props. It accepts all standard 5-inch powertrain components and mounts modern digital VTX units natively.
