T-Motor Flame 70A 6S ESC

The T-Motor Flame 70A is a single-channel ESC built for heavy-lift and agricultural multirotors, rated for 4-6S LiPo power. Continuous current is 70 A with an 80 A peak for up to 10 seconds, giving useful headroom for U12-class and similar agricultural motors.

Key features

• Rated 70 A continuous and 80 A peak (10S), for one motor per ESC on multirotor and agri-drone builds
• 4-6S LiPo input, so the same ESC covers everything from a 4S FPV setup to a 6S heavy-lift motor
• CNC aluminium enclosure and a layered internal structure for efficient heat dissipation under sustained load
• 500 Hz refresh rate on a Nano-Tech PCB for smoother throttle response at high current
• Matched by T-Motor to its U12 V2 KV60 and P60 Pin KV340 motors, and compatible with MN5208, MN5212 and U8-series motors

Specifications

• Input voltage: 4-6S LiPo
• Continuous current: 70 A
• Peak current: 80 A (up to 10 seconds)
• Refresh rate: 500 Hz
• Enclosure: CNC aluminium

Wire it as a standalone ESC close to its motor, and size the battery and wiring for the full 70 A continuous draw when running at 6S.
