Skydroid T12 2.4GHz 12CH Radio with R12 Receiver & FPV Camera

The Skydroid T12 is an integrated 12-channel radio transmitter, digital video link, and telemetry system designed for agricultural, industrial, and long-range UAVs. By combining a 2.4GHz control link with digital video and data transmission, it eliminates the need for separate VTX and telemetry radios on your ArduPilot or PX4 heavy-lift builds.

Key features

• Integrates control, telemetry, and digital video transmission over a single 2.4GHz link

• Includes the R12 receiver and a 3-in-1 FPV camera with an integrated 8W high-brightness LED

• Connects directly to Android smartphones or tablets via USB or Bluetooth for ground control station functionality

• Supports Skydroid FPV, Mission Planner, and QGroundControl applications

• Built-in 4000mAh battery provides extensive field operating time

Specifications

• Channels: 12

• Operating frequency: 2.400–2.483 GHz

• Operating range: Video up to 20 km at SD resolution, data link up to 30 km

• Radio battery: Built-in 3.7V 4000mAh Li-ion

• Working current: 130 mA

• Charging port: Micro-USB

• Radio weight: 490 g

• Radio dimensions: 225 x 123 x 35 mm

• Receiver outputs: PWM, SBUS, UART

• Receiver weight: 14 g

• Camera voltage: 5V

• Supported firmware: ArduPilot, PX4

• In the box: T12 transmitter, R12 receiver with antenna, 3-in-1 camera, connecting cable set, carrying case

This combo is purpose-built for complex surveying, inspection, and agricultural spraying missions. The included device mount accommodates most smartphones, transforming the T12 into a complete ground control station when paired with your preferred flight planning application.
