Skydroid G30 GNSS Receiver with GR01/GR03 Antenna
SKU SKYDROID-G30-GR01
Choose variant
Free shipping. Pan India delivery from Gurugram, Haryana.
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Questions about this part? Ask us on WhatsApp- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
The Skydroid G30 is a dual-band GNSS receiver compatible with GPS, GLONASS, Galileo and BeiDou constellations, offered here bundled with either a GR01 or GR03 antenna. Built around a high-precision GNSS chipset, it delivers centimetre-level accuracy when paired with RTK correction sources and supports both UART and I²C interfaces for integration with ArduPilot, PX4 and INAV flight controllers. Suited to fixed-wing long-range platforms, heavy-lift cinelifters and survey drones where position hold and waypoint navigation demand better accuracy than standard GPS modules.
Key features
Multi-constellation reception (GPS, GLONASS, Galileo, BeiDou) for faster satellite acquisition and improved accuracy in challenging environments
RTK-ready design accepts RTCM correction streams over UART or USB for centimetre-level positioning
Dual interface support: UART and I²C for flexible wiring with Pixhawk, Cube and other autopilot platforms
Compact form factor with integrated barometer and compass for single-unit mounting
Choice of antenna: GR01 for long-range UAVs or GR03 for survey and precision applications
Specifications
Constellations: GPS, GLONASS, Galileo, BeiDou
Interfaces: UART, I²C
Supported firmware: ArduPilot, PX4, INAV
Integrated sensors: Barometer, compass
Mount the G30 on a vibration-damped mast or top plate away from high-current wiring and ESCs to minimise magnetic interference. When using RTK correction, ensure a clear sky view and stable telemetry link for uninterrupted RTCM delivery.
