Beitian BN-220 GPS/
₹4,899Incl. GST
SKU BEITIAN-BN220-GPS
Compass Included: NoMade in India: NoBrand: BeitianRTK Support: No
Dispatched within 2–3 business days — quality-checked in Gurugram
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Questions about this part? Ask us on WhatsApp
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The Beitian BN-220 is a GPS and GLONASS positioning module with a TTL-level UART output, aimed at RC drone and single-board-computer GNSS projects.
Key features
- Dual-constellation GPS + GLONASS reception improves fix reliability compared with single-constellation modules.
- Four-pin TTL interface (GND, TX, RX, VCC) wires directly into a flight controller's GPS UART.
- Accepts 2.8-6.0V on the power pin, giving flexibility across 3.3V and 5V host boards.
- Works without an additional driver on Raspberry Pi and similar single-board computers.
- TX LED flashes on data output; the PPS LED signals fix status, off when unfixed and flashing red once fixed.
Specifications
- GNSS chipset: u-blox M8
- Constellations: GPS, GLONASS
- Interface: TTL UART (GND, TX, RX, VCC)
- Voltage: 2.8-6.0V
Confirm your flight controller's GPS port wiring and voltage before connecting; this module has no built-in compass or RTK support.
| Compass Included | No |
|---|---|
| Made in India | No |
| Brand | Beitian |
| RTK Support | No |
| GNSS Chipset | u-blox M8 |
| Barometer | No |
