iFlight Borg 60R 60A 4-in-1 ESC (3–8S)

The iFlight Borg 60R is a 4-in-1 ESC built for demanding FPV platforms — 7-inch long-range cruisers, X-Class rigs and heavy-lift cinelifters — that need sustained high current on a 3–8S pack.

Key features

• Rated 60A continuous per motor with a 65A burst for 10 seconds, enough headroom for large-stator motors on high-pitch props.
• Accepts 3–8S LiPo/LiHV input, letting builders run higher voltage at lower amp draw than a standard 6S setup.
• Integrated anti-spark circuit and TVS transient suppressor give double protection against voltage spikes.
• High-polymer capacitors are built into the board, removing the need for an external capacitor on 5-inch racing builds.
• FPC ribbon connection to the flight controller, with bidirectional DShot and telemetry support.

Specifications

• Input voltage: 3–8S LiPo/LiHV
• Continuous current: 60 A
• Burst current: 65 A (10s)
• MCU: STM32G071
• Driver: FD6288
• Firmware: BLHeli_32 (target IFLIGHT_BLITZ_G3)
• Protocols: DShot150/300/600, MultiShot, OneShot
• Current sensor: No
• BEC: None
• Mounting: 20x20mm, Φ4mm
• Dimensions: 45 x 52mm
• Weight: 14.5 g
• In the box: ESC, cable set, 4 silicone grommets

Pair the Borg 60R with a heavy-lift flight controller and adequate capacitor filtering — it carries no onboard BEC or current sensor of its own.
