Eachine EV100 720x540 5.8GHz 72CH FPV Goggles
SKU EACHINE-EV100-BLACK
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The Eachine EV100 is a box-style analogue FPV goggle set with a 720x540 display and a 72-channel 5.8GHz receiver, built for everyday flying and bench testing on conventional analogue video links.
Key features
Dual antennas feed a single 72-channel receiver with auto search, finding the strongest signal automatically.
28° diagonal field of view, with adjustable focal length and 58-68mm IPD adjustment for a range of pilots.
Three racing modes (4, 6 or 8 pilots) space channels 60-80MHz apart to cut interference at group flying sessions.
Built-in fan reduces lens fogging, and AV input/output supports an external DVR or HDMI-to-AV module.
Supplied with a 2S 7.4V 1000mAh battery, charged over a separate USB cable.
Specifications
Display: 720x540, 4:3
Field of view: 28° diagonal
Receiver: 72-channel 5.8GHz, 3dBi RP-SMA antennas
Focal adjustment: -4.00 to +1.50 dioptres
Power input: 7.4V (2S), low-voltage warning at 6.8V
Dimensions: 165 x 76 x 30mm
Weight: 221g with battery and antennas
Operating temperature: -10°C to +40°C
Pair with an analogue 5.8GHz VTX rather than a digital air unit, and use the debug mode only with a VTX that supports pitmode and the extra 5300MHz frequency.
| FPV System | Analog |
|---|---|
| Device Type | Goggles |
| Goggle Type | Analog |
| Made in India | No |
| Brand | Eachine |
| Frequency | 5.8GHz |
| Weight | 221 g |
| DVR | No |
