XC U80 V2 80A 12S 48V Brushless Single ESC

The XC U80 V2 is a heavy-duty 80 A single brushless electronic speed controller designed for heavy-lift, agricultural and industrial multirotors. Built to handle high-voltage 5-14S LiPo power systems, it features an IP67-rated glue-filled housing that seals the electronics against dust, dirt and water ingress during demanding field operations.

Key features

• Delivers 80 A continuous and 120 A peak current under active cooling.

• Accepts broad high-voltage inputs from 5S up to 14S LiPo.

• IP67-rated sealed enclosure protects against harsh weather and agricultural spraying environments.

• Operates safely in outdoor temperatures ranging from -25 deg C to 60 deg C.

• Compatible with both 3.3V and 5V PWM throttle signals.

Specifications

• Model: U80 V2

• Continuous current: 80 A

• Peak current: 120 A

• Input voltage: 5-14S LiPo

• Signal frequency: 50-500 Hz

• Throttle pulse width: 1050-1940 us

• BEC: None

• Wire gauge: 12 AWG / 14 AWG

• Protection rating: IP67

• Operating temperature: -25 deg C to 60 deg C

• Weight: 90 g (excluding wires)

Choose this ESC for outdoor multirotor builds where reliability in damp or dusty conditions is critical. Because this unit lacks an internal BEC, you must wire a separate voltage regulator to your power distribution board to power your flight controller and avionics. Always mount the ESC where it receives adequate propeller downwash, as the 80 A continuous rating relies on active airflow.
