XC 120A 12S 48V 12HP Brushless Motor ESC
₹12,499Incl. GST
SKU XC-120A-12S-48V-ESC
ESC Current: 120 AInput Voltage: 5–14SMade in India: NoBrand: XC
Dispatched within 2–3 business days — quality-checked in Gurugram
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Questions about this part? Ask us on WhatsApp
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The XC 120A ESC is a high-current brushless motor controller built for heavy-lift UAVs and other high-voltage brushless propulsion systems, rated at 48V/12S with a wide LiPo input range.
Key features
- Delivers 120A continuous current with a 180A instantaneous peak for demanding heavy-lift loads.
- Accepts 5S-14S LiPo input, giving headroom above its rated 12S/48V system class.
- IP67-rated housing resists dust and water for outdoor and industrial use.
- Operates from -25°C to 60°C, suiting a wide range of field conditions from cold mountain sites to hot summer days.
- 12AWG power leads handle sustained high current with low resistive loss between battery and motor.
Specifications
- Continuous current: 120A
- Peak current: 180A
- Input voltage: 5S-14S LiPo, rated 12S / 48V
- Weight: approx. 140g
- Dimensions: 81.8 x 41.2 x 23.2mm
- Protection: IP67
Confirm your motor's current draw and battery voltage against these ratings, and provide adequate cooling airflow for sustained high-current operation in the field.
| ESC Current | 120 A |
|---|---|
| Input Voltage | 5–14S |
| Made in India | No |
| Brand | XC |
| Weight | 140 g |
