Vector Technics 8015 SL Motor 100KV

The Vector Technics 8015 SL 100KV is an Indian-made heavy-lift motor built for agricultural, survey and cinelifter platforms that need serious low-end torque. Its wide 80mm stator and low 100KV winding are matched to 12S LiHV power systems and propellers up to 32 inches.

Key features

• Made in India for enterprise, agriculture and heavy-payload UAV airframes.
• 100KV winding tuned for efficient 12S LiHV (44–52V) power systems.
• 36S42P stator and magnet configuration with dual bearings for sustained heavy-load reliability.
• 8mm output shaft and a 36mm bolt-circle mount handle large propellers without flex.
• SL (Super Light) bell and base construction keeps dry weight down to maximise payload.

Specifications

• Stator size: 8015
• KV: 100
• Input voltage: 12S LiHV (44–52V)
• Max continuous current: 40A (180s)
• Max continuous power: 1495W (180s)
• Max thrust: 14 kg
• Shaft: 8mm
• Motor size: 88.4 x 34 mm
• Bearings: dual 619/8-2Z
• Motor mount: 4x M4 on 36 mm circle
• Prop mount: 4x M4 on 23 mm circle or 4x M3 on 20 mm circle
• Ingress protection: IP45
• Weight: 420g
• Max propeller size: 32 inches

Pair this motor with a large-format industrial ESC and propellers up to 32 inches for agricultural spraying rigs, heavy cinelifters or other high-payload multirotors.
