Vector Technics 6015 PRO Motor

The Vector Technics 6015 PRO is a heavy-duty brushless motor engineered for X-Class, large-scale cinelifters, and high-payload long-range FPV builds. Manufactured in India, this motor pairs a massive 6015 stator with high-quality copper winding to deliver the immense torque required to spool up oversized propellers with precision. Whether you are lifting heavy cinema camera payloads or building a high-endurance agricultural drone, the 6015 PRO provides the thermal mass and magnetic authority needed for stable, reliable flight under extreme loads.

Key features

• Massive 6015 stator: Delivers exceptional torque for spinning oversized propellers on heavy-lift and X-Class builds.
• Two KV options: Choose 340KV for high-power cinematic rigs, or 170KV for high-voltage industrial platforms.
• Indian manufacturing: Precision-machined and wound locally for dependable quality control and heavy-duty performance.

Specifications

• Brand: Vector Technics
• Stator Size: 6015
• Available KV: 170KV, 340KV
• Country of Origin: India
• Configuration: 24N28P
• Max thrust: 9.5 kg
• Max propeller size: 24 inches
• 170KV: 44-52 V (12S LiHV), 35 A / 1634 W continuous (180 s), 69.5 x 35.7 mm, 380 g
• 340KV: 6S, 40 A / 900 W continuous, 69.5 x 47.7 mm, 420 g with wires, specified with 22-inch props
• Shaft: 6 mm
• Bearings: triple 626-2Z
• Motor mount: 4x M4 on 30, 40 or 50 mm circles
• Prop mount: 6x M3 on 54 mm circle; 4x M3 on 12, 18 or 20 mm circles
• Ingress protection: IP45
• Design life: 1000 hours

The 340KV variant is specified with 22-inch propellers on 6S power for large cinelifters and heavy-lift rigs. For maximum efficiency on endurance, agricultural, or long-range heavy-lift rigs, pair the 170KV motor with a 12S drivetrain and 18-inch to 22-inch props.
