Vector Technics 6020 Pro Motor

The Vector Technics 6020 Pro is a heavy-lift brushless motor engineered for demanding commercial drone applications. Featuring a 6020 stator and wound for a low 180KV, this high-torque power plant is specifically designed for large-scale agricultural multirotors, industrial inspection rigs, and heavy-payload cinelifters operating on high-voltage power.

Key features

• Massive 60x20mm stator volume delivers the sustained torque required for lifting commercial payloads without thermal throttling.
• 180KV winding optimises electrical efficiency for high-voltage setups, typically targeting 12S lithium systems.
• Mechanically built to drive large-diameter heavy-lift propellers (commonly 21 to 24 inches) on extended long-range mapping or spray flights.
• Locally manufactured in India, ensuring strict quality control and easy parts availability for enterprise drone builders.

Specifications

• KV: 180KV
• Configuration: 24N28P
• Voltage range: 44-52 V (12S LiHV)
• Max continuous current (180 s): 47 A
• Max continuous power (180 s): 2209 W
• Max thrust: 14 kg
• Max propeller size: 26 inches
• Motor size: 69.5 x 40 mm
• Shaft: 6 mm
• Bearings: triple 619/6-2Z
• Motor mount: 4x M4 on 30 mm circle
• Prop mount: 6x M3 on 54 mm circle; 4x M3 on 12, 18 or 20 mm circles
• Ingress protection: IP45
• Design life: 1000 hours
• Weight: 425 g

This motor is ideally suited for custom agricultural hexacopters, heavy-duty survey octocopters, and X-Class cinematic builds that demand consistent, reliable thrust during sustained high-load operations.
