TBS Lucid FC Freestyle — AT32F435 ICM-42688P 20×20 Flight Controller
₹4,299Incl. GST
SKU TBS-LUCID-FC-FREESTYLE-F4
Integrated Receiver: NoMounting Size: 20x20Integrated VTX: NoFC Processor: AT32F435
Dispatched within 2 business days — quality-checked in Gurugram
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Questions about this part? Ask us on WhatsApp
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The TBS Lucid FC Freestyle is a 20x20mm flight controller built around the AT32F435 processor, aimed at 5-inch freestyle and cinematic quads that need reliable Betaflight performance without excess bulk.
Key features
- AT32F435 processor runs Betaflight with headroom for blackbox logging and RPM filtering.
- ICM-42688P gyro gives a clean, low-noise signal for tight PID tuning.
- Dedicated DJI O3 Air Unit connector simplifies wiring on digital HD builds.
- Built-in ESC and receiver pads keep the wiring loom short on a compact stack.
- 20x20mm mounting holes fit compact freestyle stacks.
Specifications
- Processor: AT32F435RMT7 (288MHz)
- Gyro: ICM-42688P
- OSD: AT7456E
- Blackbox: 8MB flash
- UARTs: 6
- Motor outputs: 4, with ESC telemetry and current sensor input
- BEC: 9V/2.5A, 5V/2A
- Input voltage: 3-6S LiPo
- Mounting: 20x20mm
- Board size: 31 x 29 mm
- Weight: 4.5 g
- In the box: flight controller, plug-and-play ESC cable, DJI O3 cable, 4 M3 rubber dampers, 4 M3x8 screws
Pairs directly with DJI O3 Air Unit builds and 20x20mm 4-in-1 ESCs for a tidy freestyle setup.
| Integrated Receiver | No |
|---|---|
| Mounting Size | 20x20 |
| Integrated VTX | No |
| FC Processor | AT32F435 |
| Gyro | ICM42688P |
| Input Voltage | 3–6S |
| Made in India | No |
| Brand | TBS |
| Supported Firmware | Betaflight |
| Barometer | No |
| UARTs | 6 |
| Weight | 4.5 g |
| Compass Included | No |
| Motor Outputs | 4 |
