Skystars 4.9/
₹4,769Incl. GST
SKU SKYSTARS-VTX-3W-56CH
VTX Power: 3000 mWMounting Size: 20x20Antenna Connector: MMCXMade in India: No
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Questions about this part? Ask us on WhatsApp
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The Skystars 4.9/5.8G 3W video transmitter is built for long-range FPV flights that need extra signal penetration. It outputs up to 3000mW across both the 4.9GHz and 5.8GHz bands, giving a resilient analogue link for mountain surfing, deep bando diving and heavy-lift cruising.
Key features
- Up to 3000mW maximum output, selectable down through PIT/25mW/400mW/1000mW for pit-lane testing.
- Dual-band 4.9GHz and 5.8GHz operation gives access to less-crowded frequencies when local 5.8GHz traffic is heavy.
- IRC Tramp telemetry lets you change band, channel and power directly from the OSD or radio.
- 20x20mm mounting pattern with an MMCX antenna connector fits standard analogue VTX bays.
Specifications
- Input voltage: 9-35V
- Output power: PIT / 25 / 400 / 1000 / 3000 mW
- Frequencies: 4.9GHz and 5.8GHz
- Channels: 56, including Raceband
- Mounting: 20x20mm (M2)
- Antenna connector: MMCX
- Control protocol: IRC Tramp
- Dimensions: 38 x 38 x 13 mm
- Weight: 31.4 g
This VTX runs hot at full power, so mount it where it gets airflow and always attach an antenna before powering it on. Keep to the legal power limit for your region.
| VTX Power | 3000 mW |
|---|---|
| Mounting Size | 20x20 |
| Antenna Connector | MMCX |
| Made in India | No |
| Brand | Skystars |
| Frequency | 5.8GHz, 4.9GHz |
| Weight | 31.4 g |
| Input Voltage | 3–8S |
| VTX Control | Tramp |
