iFlight BOB57 O4 Pro Frame Kit

The iFlight BOB57 O4 Pro is a 6-inch cinematic long-range frame built around the DJI O4 Air Unit Pro. It sits between an agile 5-inch freestyle quad and a 7-inch cruiser: open propellers on a 278mm wheelbase and thick 6mm arms give it the stability to carry a full-size action camera without the drag of ducts.

Key features

• Sized for 6-inch propellers, bi-blade or tri-blade.
• Thick 6mm carbon arms for a rigid frame that tunes cleanly.
• Camera and VTX mounting for the DJI O4 Air Unit Pro.
• Open-prop layout — a cinematic long-range frame, not a ducted cinewhoop.

Specifications

• Propeller size: 6-inch
• Wheelbase: 278mm
• Arm thickness: 6mm
• Plate thickness: 1.5mm bottom, 2mm top, 2.5mm upper
• Dimensions: 165 × 225 × 34mm
• Flight stack mounting: 20x20mm / 30.5x30.5mm (M3), max stack height 22mm
• VTX mounting: 20x20mm / 25.5x25.5mm, max VTX height 22mm
• Motor mounting: 16x16mm
• Frame weight: 305g
• Video system: DJI O4 Air Unit Pro
• In the box: frame kit, TPU parts (dual-antenna VTX mount), 220mm MIPI video cable for the O4 Air Unit Pro, 4 motor wire shield tubes, battery anti-slip pad, 2 battery straps, screw bag; IPEX-to-SMA adapter cables and anti-spark filter not included

iFlight pairs the BOB57 with its BOB57 2506 1500KV motors on 6S — a combination that favours smooth, efficient cruising with a camera on board.
