AMAX Competition 2312 Brushless Motor 1350KV/1600KV

The AMAX Competition 2312 is a tall-stator brushless motor for 7-inch long-range and heavier FPV builds, offered in 1350KV and 1600KV windings with a standard 16 × 16 mm M3 mount.

Key features

• 2312 stator: 23 mm × 12 mm, far taller than a 2306 or 2308, giving the torque to hold larger props at speed.

• 1350KV option: the lower-KV choice for larger props and efficient cruising.

• 1600KV option: a livelier throttle on smaller props at the same battery voltage.

• 16 × 16 mm M3 mount: matches the common motor bolt pattern on 5–7-inch FPV arms.

• Sold singly: each unit is one motor; order four for a quad.

A 2312 weighs more than a 2306, so it pays off where props are large or the airframe carries an action camera or a long-range pack. Check the shaft against your prop hubs, and choose an ESC with current headroom, since a tall stator on big props can pull more amps than a 5-inch setup.
