Hobbywing XRotor X11 Plus 85KV 12-14S Integrated Power System

The Hobbywing XRotor X11 Plus is an integrated propulsion unit that combines motor, ESC and propeller mount in one arm-end assembly, built for heavy-lift agricultural spraying and spreading drones on 12-14S LiPo. It suits multirotors planned around 15-18 kg of takeoff weight per rotor.

Key features

• 111x18 mm stator at 85KV, matched to the 43x14 (4314) carbon-plastic folding propeller

• Up to 37 kg of thrust per rotor at 54 V, sea level

• 2130 W rated output power per unit

• IPX6 ingress protection against spray, rain and field dust

• CAN communication by default (DataLink V2) with an optional serial port; PWM throttle also accepted

• Clamps directly onto a 50 mm outer-diameter arm tube

Specifications

• KV: 85 rpm/V

• Stator size: 111 x 18 mm

• Recommended battery: 12-14S LiPo

• Max input voltage: 61 V

• Max input current: 150 A (with good heat dissipation)

• Max thrust: 37 kg/rotor (54 V, sea level)

• Recommended takeoff weight: 15-18 kg/rotor (54 V, sea level)

• Rated output power: 2130 W

• Propeller: MFP 43x14

• Arm tube: 50 mm outer diameter

• Total weight: 2490 g

• Ingress protection: IPX6

• Operating temperature: 0-50 °C

• Throttle signal: PWM 50-500 Hz, 1050-1950 µs, 3.3 V/5 V logic

• BEC: None

Order CW and CCW units to match each arm's rotation, and pick the propeller option unless you are reusing existing 4314 blades. A 12S or 14S pack and a flight controller with CAN or PWM motor outputs complete the set-up.
