Flywoo GOKU H743 Pro Mini FC (20×20)

The Flywoo GOKU H743 Pro Mini is a high-performance 20x20mm flight controller designed for space-constrained builds requiring massive processing headroom, from autonomous long-range rigs to tightly packed 5-inch freestyle quads. Powered by a 480MHz STM32H743 MCU, it easily handles advanced gyro filtering, high loop rates, and complex GPS navigation tasks without breaking a sweat.

Key features

• 480MHz STM32H743 processor delivers zero-latency loop times and runs complex Betaflight, INAV, or ArduPilot configurations with ease.

• Seven hardware UARTs provide ample connectivity for HD video systems, GPS modules, telemetry, and serial receivers.

• Integrated 5V/2A and 10V/2A dual BECs reliably power DJI O3, Walksnail, or Caddx Vista digital air units alongside your peripherals.

• Built-in barometer enables accurate altitude hold for waypoint missions and autonomous flights.

• Eight motor outputs for X8 octocopter layouts, and 512MB of onboard blackbox storage.

Specifications

• MCU: STM32H743

• Gyro: 2x ICM42688P (dual)

• Input Voltage: 2-6S LiPo/LiHV (7.4-26 V)

• UARTs: 7

• Motor outputs: 8

• BEC: 5V @ 2A, 10V @ 2A

• Barometer: DPS310 / SPL06

• Blackbox: 512MB onboard

• Supported Firmware: Betaflight, INAV, ArduPilot

• Firmware target: Flywoo H743PRO

• Mounting Size: 20x20mm (M2 holes)

• Dimensions: 32 x 29 x 8.4 mm

• Weight: 5.8g

• In the box: flight controller, cable set (ESC, DJI O4, receiver, GPS, camera), M2 damping balls and nuts

With its flagship H7 processing power and extensive peripheral support, this flight controller is the ideal brain for complex micro long-range builds or HD cinewhoops where mounting space is at a premium.
