DYS 100A 2-6S Brushless ESC with 5V/
SKU DYS-ESC-100A-2-6S-XT90
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The DYS 100A is a high-current single brushless ESC for large fixed-wing aircraft, helicopters and big multirotors on 2S to 6S LiPo. A 5V/6A switching BEC feeds the receiver and servos from the main pack, and it comes with an XT90 battery plug and 4mm motor bullets already soldered on, sized for the current it handles.
Key features
- 100A continuous with a 120A peak rating for short bursts of full throttle
- Runs on 2-6S LiPo or 5-18 cell NiMH packs
- Switching BEC stays cooler than a linear regulator at 6S and leaves 6A of headroom for a full set of servos
- Low-voltage cutoff, over-heat protection and throttle signal-loss protection
- Normal and Soft start modes, plus throttle range calibration to suit any transmitter
Specifications
- Continuous current: 100A
- Peak current: 120A
- Input: 2-6S LiPo / 5-18 cell NiMH
- BEC: 5V / 6A switching (SBEC)
- Battery connector: XT90
- Motor connectors: 4mm bullets
- Weight: 73g
- Dimensions: 62 x 35 x 12 mm
Size it so the motor's full-throttle draw on your prop stays under 100A, with the 120A figure kept as burst margin. Give it airflow inside the fuselage, use Soft start on helicopters and geared drives, and recalibrate the throttle range whenever you change transmitter or receiver.
| ESC Current | 100 A |
|---|---|
| Input Voltage | 2–6S |
| Made in India | No |
| Brand | DYS |
| Weight | 73 g |
| BEC | Yes |
| Motor Type | Brushless |
