Tarot TL2996 12S Power Distribution Board

The Tarot TL2996 is a power distribution board for 12S heavy-lift multirotors, built to split one high-voltage battery feed out to several ESCs from a single, tidy connection point.

Key features

• Accepts two 6S packs wired in series for 12S input, or a single 6S pack for a 6S build.
• Uses XT90 plugs on the input, with 10AWG silicone wire rated for high current.
• Provides two 12S (XT60) output pads, or two 6S (XT60) outputs when run from a single 6S pack.
• A custom ESC signal hub uses an anti-mis-insertion design to keep wiring correct under vibration.

Specifications

• Rated input: 12S LiPo (or 2 x 6S in series)
• Input wire: 10AWG silicone, up to 185mm
• Output connectors: XT60

Confirm your battery, ESCs and wiring are all rated for 12S before powering the board — it distributes current but doesn't limit it.
