T-Motor MN601-S KV170 + Alpha 60A HV + 30mm Tube Mount Combo

A matched T-Motor propulsion set for one arm of a heavy-lift multirotor: the MN601-S KV170 Navigator motor, an Alpha 60A HV FOC ESC and a motor mount sized for 30 mm arm tubes. It suits agricultural sprayers, cargo and inspection airframes running 6-12S packs and 20-21 inch propellers.

Key features

• Low-KV torque: the 170KV, 24N28P motor is rated for 6-12S LiPo and produces up to 6.6 kg of thrust on T-Motor's figures.

• FOC sine-wave control: the Alpha 60A HV ESC handles 60 A continuous on 12S (18-50.4 V) for precise, stable and efficient motor drive.

• Built for outdoor work: IP45 motor with a rust-treated silicon-steel stator and magnets rated to 150 °C.

• Arm-ready: the mount fits 30 mm arm tubes, so motor, ESC and mount arrive as one matched set per arm.

• Propeller not included: pair it with 20-21 inch props.

Specifications

• Motor: MN601-S KV170

• Motor size: Ø68.8 × 34.9 mm

• Configuration: 24N28P

• Motor weight: 250 g incl. cable

• Rated voltage: 6-12S LiPo

• Idle current (20 V): 0.8 A

• Peak current (180 s): 30 A

• Max power (180 s): 1500 W

• Internal resistance: 115 mΩ

• Shaft: 6 mm in / 6 mm out

• Max thrust: 6.6 kg

• Motor protection: IP45

• ESC: Alpha 60A HV FOC, 60 A continuous, 18-50.4 V (12S)

• Arm mount: 30 mm tube

• Recommended props: 20-21 inch

Order one combo per arm, four for a quad or six for a hexa, and run each ESC signal lead to a motor output on your flight controller.
