Skydroid G30 10.1" Ground Station Remote Controller with GR01/GR03 Receiver

The Skydroid G30 is a handheld ground control station for industrial, agricultural and long-range UAVs. It combines the radio transmitter, the HD video receiver and a 10.1-inch Android display in one unit, so the pilot flies, watches the live feed and runs a mission-planning app from the same controller. Choose it with the GR01 or the GR03 air receiver.

Key features

• 10.1-inch 1920×1200 touchscreen, bright enough to read in direct sunlight.
• Android on a Qualcomm 6nm processor — run ground-station and mapping apps directly on the controller.
• 2.4GHz / 5.8GHz dual-band link with automatic frequency hopping, carrying HD video and telemetry up to 30 km.
• Optical-fibre link option for ultra-low-latency tethered operation.
• Rich I/O on the controller: fibre, USB-C, SIM card slot, RJ45 Ethernet, PPM and USB-A.
• Built-in lithium-ion battery rated for 6–8 hours per charge, with 33W PD fast charging.

Receiver options

• GR01: compact receiver for aircraft that need the control link, HD video and telemetry.
• GR03: full-featured industrial receiver — dual serial ports for telemetry and data, dual Ethernet, SBUS, PWM outputs, audio output and a fibre interface.

Specifications

• Display: 10.1", 1920×1200, sunlight-readable
• Link: 2.4GHz / 5.8GHz dual-band, up to 30 km
• Battery life: 6–8 hours
• Charging: PD 33W
