Hawkeye Little Pilot 4.5 Inch 4.9G-6G 108CH FPV Monitor with DVR

The Hawkeye Little Pilot is a 4.5-inch all-in-one FPV monitor with a built-in wide-band video receiver, DVR and battery. It covers the 4.9 GHz, 5.8 GHz and 6 GHz bands across 108 channels, so it works with standard 5.8 GHz analog VTXs as well as wide-band transmitters. It makes a compact ground screen for beginners, spotters and fixed-wing pilots who prefer a monitor to goggles.

Key features

• Built-in DVR: records and plays back footage on the monitor itself, which helps when tracing a downed model from its last frames.
• No blue or black screen on weak signal: the picture stays up with noise instead of blanking as range runs out.
• Auto and manual channel scan: finds your VTX without DIP switches.
• Internal battery: about 2.5 hours per charge, with fast power-on.
• AV input and output: take video from another receiver or pass it on to a second screen or recorder.
• Switchable 16:9 / 4:3 screen at 800×480 with an LED backlight and under 10 ms response time.

Specifications

• Screen: 4.5 in, 800×480, LED backlight
• Aspect ratio: 16:9 / 4:3
• Response time: under 10 ms
• Frequency: 4.9–6 GHz, 108 channels
• Video format: PAL / NTSC (analog only)
• DVR resolution: 720×288 (PAL), 720×240 (NTSC)
• Storage: SD card 8–32 GB, Class 10 (not included)
• Antenna connector: RP-SMA
• Battery life: about 2.5 hours
• Dimensions: 128.5 × 83.5 × 16.8 mm
• Weight: 220 g

This monitor receives analog video only and will not display DJI, Walksnail or HDZero digital feeds. For the cleanest picture and recordings, set your FPV camera to NTSC, and use an RP-SMA antenna whose polarisation matches the one on your VTX.
