Alex 2207.5 Brushless FPV Motor, 1750/1950KV 6S

The Alex 2207.5 is a made-in-India 6S brushless motor for 5- and 6-inch FPV freestyle and racing quads, built on a 22 × 7.5 mm stator with N52H magnets. Choose 1750KV for 6-inch props or efficient 5-inch cruising, or 1950KV for punchier 5-inch freestyle.

Key features

• 12N14P with N52H magnets: the standard high-performance configuration for 5-inch class motors.
• Dynamically balanced: to 3 mg or better for low vibration and cleaner gyro data.
• 20AWG, 200 mm leads: long enough to reach a centre-mounted ESC on most frames.
• 6S rated: up to 704 W (1750KV) or 799 W (1950KV), with a 50 A ESC recommended.
• Precision bearings: low-resistance bearings and a cooling-oriented design for long sessions.

Specifications

• Stator: 22 mm diameter × 7.5 mm height
• Configuration: 12N14P
• Magnets: N52H
• Battery: 6S LiPo (22.2 V nominal)
• Max power: 704 W (1750KV) / 799 W (1950KV)
• Max current: 29 A (1750KV) / 33 A (1950KV)
• Idle current at 10 V: 1.1 A (1750KV) / 1.2 A (1950KV)
• Recommended ESC: 50 A
• Test propeller: Gemfan 6030 (1750KV) / Gemfan 5040 (1950KV)
• Dynamic balance: 3 mg or better
• Leads: 20AWG, 200 mm
• Weight: 34 g

Sold individually, so order four for a quad. Pair it with a 6S-rated ESC of at least 50 A per motor and check your frame's motor-mount pattern before ordering.
