Skyzone SKY04X Pro OLED FPV Goggles - 5.8GHz

The Skyzone SKY04X Pro is a premium OLED FPV goggle designed for demanding analogue and digital pilots. Featuring a high-resolution 1920x1080 OLED display and an immersive 52-degree field of view, it delivers exceptional clarity for freestyle, racing, and long-range builds. The included 5.8GHz Steadyview V3.3 receiver merges two video signals into one, preventing the image tearing and rolling often seen in multipath environments. With a 720p 100fps HDMI input, it also serves as a top-tier display for digital standalone receivers like Walksnail Avatar or HDZero.

Key features

• High-definition 1920x1080 OLED displays with a massive 52-degree FOV

• Included 5.8GHz Steadyview V3.3 receiver merges signals for tear-free analogue video

• Supports external digital VRXs via a high-framerate HDMI input

• Built-in H.264 60fps DVR for high-quality flight recording on an SD card

• Adjustable focus (-6 to +2) and IPD (58–71mm) dials to perfectly tune your optics

• Accepts 2-6S LiPo or 5V USB-C power inputs for versatile field charging

Specifications

• Screen: OLED (1920x1080)

• Field of View: 52 deg

• Aspect Ratio: 4:3 / 16:9 (switchable)

• Receiver: 5.8GHz 48CH Steadyview V3.3

• Antenna Connector: SMA

• IPD Range: 58-71mm

• Focus Adjustment: -6 to +2 diopters

• DVR: H.264, 60fps (SD Card)

• Head Tracker: 3-axis accelerometer and 3-axis gyroscope

• Power Input: 6.5-25.2V (2-6S LiPo) / 5V USB-C

• Dimensions: 185x75x67mm

• Weight: 267g

• In the box: goggles, Steadyview V3.3 receiver module, wide and narrow faceplates, sponge with hook-and-loop, zip case, power cable, head-tracker cable, 2 x 5.8GHz antennas, AV cable, USB-C cable

Pair the SKY04X Pro with a matched set of high-gain directional and omnidirectional SMA antennas to maximise the Steadyview receiver's range and penetration. For digital flight, simply run an HDMI cable from your external HDZero or Walksnail VRX directly into the goggle's input port.
