SkyRC T400Q 4×100W Quattro Balance Charger

The SkyRC T400Q is a four-channel balance charger and discharger in a vertical tower case that takes up little bench space. Each port charges independently at up to 100 W and 12 A, so FPV pilots and RC racers can charge four 1-6S packs at once from mains or a DC supply.

Key features

• Four independent circuits, 100 W each for 400 W in total.
• Built-in AC power supply (100-240 V) plus an 11-18 V DC input for field use.
• Charges LiPo, LiHV, LiFe and Li-ion from 1S to 6S, NiMH/NiCd up to 15 cells and lead-acid, with AGM and cold modes.
• Built-in XT60 outputs that resist reverse connection.
• Balances at up to 500 mA, with customisable terminal voltage.

Specifications

• AC input: 100-240 V, 50/60 Hz
• DC input: 11-18 V
• Charge power: 4 x 100 W
• Charge current: 0.1-12.0 A per channel
• Discharge: 10 W, 0.1-2.0 A
• Balance current: 500 mA max
• Lithium cells: 1-6S (LiPo, LiHV, LiFe, Li-ion)
• NiMH/NiCd: 1-15 cells
• Lead-acid: 2-20 V
• Display: 2 x 16 LCD, blue backlight
• Dimensions: 186 x 103 x 209 mm
• Weight: 1610 g

At 100 W per port, a 6S pack (25.2 V at full charge) charges at roughly 4 A, so larger 6S packs take longer than on a single high-power charger. Packs with XT30 or other plugs need an XT60 adapter lead.
