SkyRC Quattro Micro 4x1cell LiPo Charger, 4x4W AC/DC

The SkyRC Quattro Micro charges four single-cell (1S) LiPo packs at once, each on its own independent output. It runs from AC mains or an 11-15V DC source. That makes it a compact bench or field charger for whoop, micro quad and micro helicopter batteries.

Key features

• Four independent 1S LiPo channels, 4W each
• Charge current adjustable from 0.1A to 1.0A
• Each port has a 4-digit LED readout for charged capacity (mAh), battery voltage and charge current
• Built-in plugs for LOSI Micro, Walkera, MX and mCPX battery leads
• Protection against short circuit, over-current, reverse polarity and incorrect DC input voltage

Specifications

• Battery type: 1S LiPo (3.7V nominal, 4.2V full)
• Channels: 4, independent
• Charge power: 4 x 4W (plus or minus 10%)
• Charge current: 0.1-1.0A (plus or minus 10%)
• AC input: 100-240V
• DC input: 11-15V
• Operating temperature: 0-50 degrees C
• Dimensions: 132 x 100 x 50 mm
• Weight: 280 g

Most current whoop packs use PH2.0 or BT2.0 plugs. Check that yours matches one of the charger's built-in plugs, or use a suitable adapter lead. Charge at 1C unless the pack maker allows more, for example 0.3A for a 300mAh battery. The charger stops at the LiPo full voltage, so LiHV packs will not reach their 4.35V full charge.
