iFlight XING2 3314 Cinelifter Motor

The iFlight XING2 3314 900KV is a large-stator brushless FPV motor built for cinelifter-style rigs, where high torque swings bigger props with smooth throttle response for carrying action cams or compact cinema payloads on a 6S pack.

Key features

• 3314 stator with a 900KV winding delivers strong low-end torque for heavy cinelifter builds
• Rated for 9 to 11-inch props, matched to 6S power for cinelifter and long-range frames
• 19x19mm motor mount and 5mm shaft, the standard fitment for cinelifter and long-range frames
• Curved N52H arc magnets and NMB bearings on a titanium alloy shaft, part of iFlight's XING2 line, give a faster throttle response than the original XING motors

Specifications

• Brand: iFlight
• Stator size: 3314
• KV: 900KV
• Shaft: 5mm
• Motor mount: 19x19mm
• Recommended props: 9-11 inch
• Input voltage: 6S
• Configuration: 12N14P
• Weight: 129 g (including wire)
• Dimensions: 41.9 x 46.8 mm
• Interphase resistance: 36.5 mOhm
• Peak current: 58.48 A
• Max power: 1366 W
• Shaft protrusion: 15 mm or 17 mm (supplied at random)
• Lead: 400 mm, 16AWG
• In the box: motor, 4x M3x12 screws, M5 flange nut

Pair this motor with a cinelifter frame that supports a 19x19mm mount, 9-11 inch prop clearance, and an ESC/battery combination that matches the 6S, 900KV rating.
