iFlight Helion 3110 900KV Motor

The iFlight Helion 3110 900KV is a wide-stator brushless motor from iFlight's XING2 range, built for 8- to 10-inch heavy-lift cinelifters and long-range macro-quads — it's the stock motor on the iFlight Helion 10 airframe.

Key features

• 31mm stator with N52H curved arc magnets and a unibell rotor deliver strong low-end torque for swinging large propellers under heavy payloads.
• Rated up to 33.6V input (6S–8S), with a peak current draw of 65.5A and a maximum output over 2,140W.
• NSK ball bearings and an 18AWG lead (260mm) suit the sustained high current of a long-range or cinelifter powertrain.
• 5mm prop shaft with a 15mm protruding length resists bending on hard landings.
• 12N14P winding configuration and 19x19mm/3mm mounting holes match the standard cinelifter bolt pattern.

Specifications

• KV: 900KV
• Stator size: 3110 (31 x 10mm)
• Configuration: 12N14P
• Weight (with wire): 77g
• Dimensions: Ø38.72 x 39.6mm
• Max input: 33.6V (6S–8S)
• Peak current: 65.5A
• Shaft: 5mm

Pair this motor with a high-current ESC (60A or higher continuous) and 8- to 10-inch cine or long-range propellers, running anywhere from 6S to 8S depending on payload and desired efficiency.
