GEPRC GEP-Vapor-D5 Frame
₹8,399Incl. GST
SKU GEPRC-VAPOR-D5
Prop Size: 5"Wheelbase: 238.4 mmCamera Size: 19mm, 20mmMade in India: No
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Questions about this part? Ask us on WhatsApp
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The GEPRC GEP-Vapor-D5 is a 5-inch DeadCat (DC) freestyle frame built to keep propellers out of the FPV and HD camera's view, combining high-strength carbon fibre arms with CNC-machined aluminium camera side panels and a front guard for extra crash protection.
Key features
- DeadCat arm geometry sweeps the props out of frame for clean, unobstructed FPV and HD footage
- CNC-machined aluminium side panels and front guard double up the camera's protection
- 5.0mm carbon fibre arms for a stiff, durable airframe that resists impact damage
- FC mounts on 20x20mm or 30.5x30.5mm patterns; VTX mounts on 20x20mm, 25x25mm or 30.5x30.5mm, for flexible stack layouts
- 19mm/20mm camera mounting width fits standard mini FPV cameras
Specifications
- Frame geometry: DeadCat (DC)
- Wheelbase: 238.4 mm
- Arm thickness: 5.0 mm
- Top/middle plate thickness: 2.0 mm
- Bottom plate thickness: 2.5 mm
- Motor mounting: 16x16 mm
- Camera mounting: 19 mm / 20 mm
- Weight: 200.8 g (±2 g)
Sized for standard 5-inch freestyle propellers, with enough stack mounting flexibility to fit most flight controller, ESC and VTX combinations.
| Prop Size | 5" |
|---|---|
| Wheelbase | 238.4 mm |
| Camera Size | 19mm, 20mm |
| Made in India | No |
| Brand | GEPRC |
| Weight | 200.8 g |
| Material | Carbon Fiber |
| Arm Thickness | 5 mm |
| Mounting Size | 20x20, 30.5x30.5 |
| Motor Mount | 16x16mm |
