GEPRC EM2812 900KV Brushless Motor
SKU GEPRC-EM2812-900KV
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The GEPRC EM2812 900KV is a high-torque, large-stator brushless motor engineered specifically for 7-inch to 9-inch long-range cruisers, heavy-lift rigs, and cinelifters. With its large 2812 stator volume, it delivers the rotational authority needed to spin large-diameter props on 6S packs.
Key features
- Large 2812 stator volume for high torque and stable payload capacity on long-range builds.
- 900KV rating suited to efficient 6S long-range cruising.
- High-strength 5mm steel shaft rated for durable use with 7 to 9-inch FPV propellers.
- High-temperature N52H magnets for consistent power output under sustained loads.
Specifications
- Brand: GEPRC
- Model: EM2812
- KV: 900
- Input voltage: 6S LiPo
- Configuration: 12N14P
- Shaft diameter: 5mm (steel), 16 mm protruding length
- Mounting pattern: 19x19mm (M3)
- Dimensions: 33 x 26.1 mm
- Leads: 18AWG, 260 mm
- Peak current: 46A
- Max power: 1010W
- Weight: 76g (including wire)
This motor is an excellent step up for pilots who find standard 2806.5 stators lack the top-end thrust needed for heavy builds. Pair the EM2812 with a 50-60A ESC and a large 6S LiPo or Li-ion pack for efficient long-range flight.
| Stator Size | 2812 |
|---|---|
| Stator Diameter | 28mm |
| Stator Height | 12mm |
| KV | 900 KV |
| Prop Mount | M5 |
| Shaft | 5mm |
| Motor Mount | 19x19mm |
| Input Voltage | 6S |
| Weight | 76 g |
| Brand | GEPRC |
| Made in India | No |
