GEPRC ELRS Nano Receiver T Antenna (2.4GHz/915MHz)

The GEPRC ELRS Nano Receiver T-Antenna is a direct replacement dipole antenna designed to maintain robust ExpressLRS radio links. Equipped with a standard IPEX1 (U.FL) connector, it serves as an exact factory replacement for GEPRC ELRS Nano receivers, but integrates flawlessly with any ELRS receiver board featuring a matching U.FL port from brands like Happymodel, BetaFPV, or Radiomaster. The antenna is available for both 2.4GHz and 915MHz frequency bands to match your specific control link hardware.

Key features

• Omnidirectional T-style dipole design provides uniform signal spread across varying flight attitudes.
• Standard IPEX1 (U.FL) connector allows for simple, secure snap-on installation without soldering.
• Durable heat-shrink casing protects the active antenna elements and central junction against crash damage and prop strikes.

Specifications

• Antenna type: Omnidirectional dipole (T-Antenna)
• Connector: IPEX1 / U.FL
• Polarisation: Linear
• Supported frequencies: 2.4GHz, 915MHz

Proper antenna placement is critical for maximising ExpressLRS range and maintaining high packet rates. Ensure the active cross-section of the T-antenna is mounted entirely clear of carbon fibre frame plates, LiPo batteries, and metallic hardware. Securing the antenna inside a flexible TPU mount at the rear of your drone provides optimal line-of-sight to the radio transmitter, significantly reducing the risk of signal shielding during aggressive freestyle manoeuvres or low-altitude proximity flying.
