BetaFPV BT2.0 Connectors (Male/
SKU BT20-FEMALE
Type: Female
Free shipping. Pan India delivery from Gurugram, Haryana.
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Questions about this part? Ask us on WhatsApp- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
Upgrade your 1S tiny whoop with the BT2.0 connector, the established standard for high-performance micro drones. Designed to replace the electrical bottleneck of traditional PH2.0 plugs, the BT2.0 standard significantly reduces internal resistance to deliver sustained voltage, minimise sag, and provide longer flight times on modern 1S brushless builds.
Key features
Replaces high-resistance PH2.0 connectors to prevent voltage sag during heavy punch-outs.
Features 1.0mm solid banana pins that provide a much larger contact area for efficient power transfer.
Built to safely handle the amp draw of high-discharge 1S LiHV batteries without overheating.
Available in separate male and female options for building custom flight controller pigtails or converting existing battery stock.
Specifications
Connector standard: BT2.0
Pin diameter: 1.0mm
Continuous current: 9A
Burst current: 15A
Contact plating: Gold
Choose the male connector for your drone's flight controller power pigtail, and the female connector when upgrading the leads on your 1S batteries.
