XL4016E1 12A 300W Adjustable Step-Down Module, 5-40V to 1.2-35V
SKU GEN-XL4016E1-12A-300W-BUCK
Free shipping. Pan India delivery from Gurugram, Haryana.
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Questions about this part? Ask us on WhatsApp- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
Adjustable DC-DC buck (step-down) converter built on the XL4016E1 regulator, taking 5–40V in and delivering a constant-voltage output anywhere from 1.2V to 35V. On a drone or the bench it turns a flight pack or power supply into a clean rail for companion computers, cameras, LED strips or test loads.
Key features
- High output — 12A peak and 300W maximum; keep continuous load to about 8A and add a cooling fan when running hard.
- Wide input range — 5–40V DC comfortably covers 3S to 9S LiPo packs.
- Heat-sinked regulator — a mounted heat sink spreads the load from the switching stage.
- Low-ripple output — four high-frequency output capacitors smooth the supply for sensitive electronics.
Specifications
- Regulator IC: XL4016E1
- Input voltage: 5–40V DC
- Output voltage: 1.2–35V, adjustable
- Output current: 12A max, about 8A recommended continuous
- Output power: 300W max
- Regulation: constant voltage
Set the output voltage with a multimeter before connecting any electronics, and keep the input a few volts above the output — a buck converter cannot step up. Double-check polarity on both terminals before powering it from a LiPo.
| Input Voltage | 3–9S |
|---|---|
| Made in India | No |
| Brand | Generic |
| Output Current | 12 A |
