ReadyToSky R2207 2450KV Motor

The ReadyToSky R2207 is a 2450KV brushless motor built for 5-inch FPV racing and freestyle quadcopters. Running on 2-4S LiPo power, its 12N14P configuration and 2207 stator format deliver responsive throttle and consistent torque during flight. It is available in a counter-clockwise (CCW) rotation version with a black bell cap and a clockwise (CW) rotation version with a red bell cap.

Key features

• 12N14P stator configuration for smooth power delivery.

• 2450KV rating tailored for 4S 5-inch FPV builds.

• Colour-coded aluminium caps (Black for CCW, Red for CW) for quick visual identification.

• Directional prop-shaft threads to ensure prop nuts self-tighten during flight.

Specifications

• Stator size: 2207

• KV: 2450

• Configuration: 12N14P

• Input voltage: 2-4S LiPo

• Shaft diameter: 4 mm

• Weight: 36 g

Choose the black-capped CCW or red-capped CW version depending on the specific arm you are assembling. The CW and CCW designations indicate the propeller shaft thread direction, ensuring standard prop nuts self-tighten rather than loosen during flight. Pair this motor with a 4S LiPo and standard 5-inch freestyle propellers.
