Quanteon QPT 2207 1800KV Brushless Motor

The QPT 2207 1800KV is a brushless motor tailored for 6S 5-inch FPV freestyle and racing builds. Utilising a taller 2207 stator volume, this motor provides a distinct flight feel with sharper high-throttle response and increased top-end speed compared to wider 2306 alternatives. It is a solid baseline powerplant for heavier freestyle chassis carrying HD action cameras.

Key features

• Optimised 1800KV rating for 6S LiPo power systems on 5-inch drone platforms
• Taller 2207 stator geometry delivers punchy acceleration and high top-end thrust
• Standard 5mm prop shaft accommodates all modern 5-inch FPV propellers
• Base matches the standard 16x16mm M3 mounting layout for universal frame compatibility

Specifications

• Stator Size: 2207
• KV Rating: 1800KV
• Recommended Voltage: 6S LiPo
• Shaft Diameter: 5mm
• Mounting Pattern: 16x16mm (M3)
• Internal Resistance: 78.5 mOhm (+/- 3)
• No-load Current: 0.57 A
• Max Current: 45 A
• Max Power: 1100 W
• Dimensions: 27 x 33 mm
• Weight: 33 g (including cable)

Pair these motors with a 45A to 50A 4-in-1 ESC and aggressive 5-inch tri-blade propellers (such as 51433 or 51466 profiles) to fully utilise their thrust band during aggressive acro manoeuvres.
