QS8L Black Anti-Spark High-Current Connector

QS8L anti-spark connector for heavy battery leads on agricultural, heavy-lift and other high-voltage drone power systems. The black fibre-reinforced nylon housing carries gold-plated brass contacts, and the anti-spark design limits the inrush spark when a high-voltage pack is plugged in. It comes as a male half, a female half or a male + female set.

Key features

• Anti-spark contacts reduce inrush current on connection, protecting the contacts and the electronics behind them
• Gold-plated brass contacts for low resistance at high current
• UL94 V0 flame-retardant housing in fibre-reinforced nylon
• Accepts heavy 8–12 AWG battery wire

Specifications

• Rated current: 110–180 A
• Wire size: 8–12 AWG
• Contacts: Gold-plated brass
• Housing: Fibre-reinforced nylon, UL94 V0
• Operating temperature: -30 °C to +150 °C
• Weight: 36 g per set
• Options: Male, female, or male + female set

Order the half that matches the lead already on your battery or ESC, or the set when wiring both sides, and pair it only with another QS8L half.
