Amass TS8-S Anti-Spark Battery Connector Female (5.1 Ohm)

Female TS8-S battery connector from Amass with a built-in 5.1 Ω anti-spark resistor, so the ESC capacitors pre-charge without an arc when a high-voltage pack is plugged in. It suits heavy-lift, agricultural and large fixed-wing power leads carrying well over 100 A.

Key features

• Rated 110 A continuous, 180 A instantaneous and 500 A peak

• 8.0 mm gold-plated brass contacts with 0.51 mΩ contact resistance

• High-temperature nylon housing with clip-on guards

• Integrated 5.1 Ω anti-spark resistor

• Takes 6–10 AWG wire

Specifications

• Gender: female

• Continuous current: 110 A

• Instantaneous current: 180 A

• Peak current: 500 A

• Contacts: 8.0 mm, gold-plated brass

• Contact resistance: 0.51 mΩ

• Anti-spark resistor: 5.1 Ω

• Wire size: 6–10 AWG

Use a high-wattage iron so the large solder cup heats through quickly without softening the housing.
