Hobbywing XRotor X6 Plus G2 150KV Motor, 80A ESC & 2480 Prop Combo

The Hobbywing XRotor X6 Plus G2 is a fully integrated motor-ESC-propeller combo for agricultural sprayers, industrial survey platforms and heavy-lift multirotors operating on 12S to 14S LiPo packs. The 6218 stator 150KV motor, FOC ESC (80 A peak) and pre-balanced 2480 folding propeller deliver 12.5 kg maximum thrust per axis, with a recommended take-off weight of about 6 kg per axis.

Key features

• Integrated FOC ESC (80 A peak) with sine-wave control provides smooth throttle response and extended efficiency for long-duration missions

• IPX6-rated sealed housing protects electronics from water ingress, dust and corrosive agricultural pesticides during spray operations

• Quick-folding 24×8" carbon-composite propeller reduces transport footprint and unfolds reliably for repeated field deployment

• Clamps directly to 30 mm or 35 mm carbon-fibre arms via the included mounting bracket, compatible with standard X-Class and industrial frames

• Available in CW and CCW rotation pairs for symmetrical motor layouts on hex and octo frames

Specifications

• Motor KV: 150 KV

• Stator size: 6218

• Input voltage: 12-14S LiPo

• ESC continuous current: 25 A (80 A peak)

• Maximum thrust: 12.5 kg per axis

• Recommended take-off weight: 6 kg per axis

• Propeller: 24×8 inches, folding, carbon-composite

• Arm tube diameter: 30 mm / 35 mm

• Waterproof rating: IPX6

• Weight: 748 g

This combo suits spray drones requiring 15–20 kg total lift capacity, survey rigs carrying RTK GNSS and mapping cameras, and X-Class builds where minimising component count and weight per axis is critical. Specify CW or CCW rotation to match your frame's motor layout.
