Hobbywing XRotor X8 Propulsion System w/ 3011 Prop - CCW

The Hobbywing XRotor X8 is a fully integrated industrial propulsion system engineered for heavy-lift agriculture and commercial multicopters. This CCW (Counter-Clockwise) module combines an 8120-class brushless motor, an 80A FOC (Field Oriented Control) ESC, and a pre-balanced 3011 folding propeller into a single plug-and-play unit. It mounts directly onto standard 40mm carbon fibre frame tubes, drastically simplifying heavy-lift builds and eliminating external ESC wiring clutter.

Key features

• Integrated design combining the motor, FOC ESC, and folding propeller assembly

• FOC technology delivers improved efficiency, lower operating temperatures, and rapid throttle response

• Fully sealed and weatherproofed to resist dust, pesticides, and moisture in harsh agricultural environments

• High-strength carbon-polymer folding blades designed for maximum thrust and payload capacity

• Built-in LED indicators for real-time status monitoring and easier visual orientation

Specifications

• Supported voltage: 12-14S LiPo

• Motor KV: 100KV

• Continuous ESC current: 80A

• Max thrust: 15.3 kg per axis

• Recommended payload: 5–7 kg per axis

• Propeller size: 30x11 inch (3011)

• Rotation direction: CCW

• Tube mounting diameter: 40mm

• System weight: 1040 g

Ideal for 16-litre to 20-litre class agricultural spraying drones or custom cinematic heavy-lifters, this system delivers the sustained torque and structural reliability required for rigorous commercial flight operations.
