GEPRC Peano 5.8GHz Antenna

The GEPRC Peano is a 5.8GHz omnidirectional FPV antenna engineered for consistent video transmission in freestyle and racing builds. Offered in 110mm and 145mm lengths, its flexible coaxial cable provides enough clearance to elevate the radiating element above your carbon fibre frame, minimizing RF blockage and multipathing during flight.

Key features

• Tuned specifically for the 5.8GHz FPV band with a highly efficient radiating element for clean video penetration.
• Semi-rigid stem holds its angle easily but yields during crashes to prevent snapping or connector damage.
• Terminated with an MMCX (110mm LHCP version) or U.FL (145mm RHCP version) connector to plug directly into compatible VTX units, eliminating the weight and signal loss of pigtail adapters.

Specifications

• Frequency band: 5.8GHz (5600–5950MHz)
• Polarization: LHCP (110mm MMCX) or RHCP (145mm U.FL)
• Connector: MMCX or U.FL
• Length: 110mm or 145mm
• Gain: 2.5 dBi
• VSWR: ≤1.5
• Impedance: 50 Ω
• Radiation efficiency: 98%
• Radome: ABS, transparent grey
• Weight: 1.6-1.8 g
• In the box: 2 antennas

The LHCP version matches the standard polarisation of digital video systems including DJI FPV, Caddx Vista, and Walksnail Avatar. Ensure your receiving goggles use antennas of the same polarisation to avoid severe cross-polarization signal degradation.
