GEPRC GEP-MK5D-LR7 7-Inch Long Range Frame
SKU GEPRC-MK5D-LR7-FRAME
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The GEPRC GEP-MK5D-LR7 is a 7-inch long-range frame built for efficient cruising and cinematic mountain surfing. Based on the Mark 5 platform, it uses a Deadcat (DC) arm layout that widens the front motor spacing so 7-inch propellers stay completely out of the HD camera feed.
Key features
- Deadcat configuration keeps propellers out of frame for clean HD video recording
- 3K carbon fibre arms resist low-frequency resonance under long-range cruise power
- CNC-machined aluminium camera side plates securely house modern digital video systems
- Separate compartments for the capacitor and buzzer, plus TPU mounts and cooling vents for the DJI O3 air unit
- Two printed action-camera bases fit the GoPro range, naked GoPro 8/10, Insta360 GO2 and Caddx Peanut
Specifications
- Model: GEP-MK5D-LR7
- Geometry: Deadcat (DC)
- Dimensions: 230 x 350 x 43 mm
- Wheelbase: 335 mm
- Weight: 230 g
- Arm thickness: 6 mm
- Top / bottom plate thickness: 2.5 mm
- FC mounting: 30.5x30.5 / 25.5x25.5
- VTX mounting: 30.5x30.5 / 25.5x25.5 / 20x20
- Motor mounting: 16x16 / 19x19
- Camera sizing: 19mm, 20mm (DJI O3 compatible)
With a spacious chassis and multiple stack mounting patterns, the MK5D-LR7 accommodates high-current ESCs and large digital video transmitters, making it a solid foundation for a long-endurance cruiser or a cinematic rig carrying a full-size action camera.
| Prop Size | 7" |
|---|---|
| Wheelbase | 335 mm |
| Camera Size | 19mm, 20mm |
| Made in India | No |
| Brand | GEPRC |
| Weight | 230 g |
| Mounting Size | 30.5x30.5, 25.5x25.5 |
| Arm Thickness | 6 mm |
| Motor Mount | 19x19mm, 16x16mm |
