Flywoo FlyLens 75 Frame Kit V1.3 (O3 Lite / O4)

The Flywoo FlyLens 75 V1.3 is a 75mm micro pusher frame purpose-built to carry the DJI O3 Lite (Naked O3) or the DJI O4 digital HD system. By using an inverted motor configuration and a vibration-damped CNC camera mount, this platform mitigates high-frequency resonance to deliver jelly-free HD footage while navigating tight indoor gaps.

Key features

• Custom CNC camera mounting designed specifically for the DJI O4 and O3 Lite
• Pusher-style (inverted) motor layout for cleaner aerodynamic airflow and improved thrust
• Durable injection-moulded 40mm propeller guards for safe proximity flying
• Three-point vibration isolation system to ensure smooth, stabilised video capture

Specifications

• Frame type: 75mm micro whoop (Pusher)
• Wheelbase: 75mm
• Supported propellers: 40mm (1.6-inch)
• Flight controller mounting: 25.5x25.5mm
• VTX mounting: 20x20mm / 25.5x25.5mm
• Motor mounting: 6.6mm / 9mm hole spacing
• Main board thickness: 2mm
• CNC gimbal thickness: 1mm
• Protective ring material: PC+
• Camera bracket: 18mm CNC bracket fitted as standard; a 14mm bracket is available separately
• Supported VTX: DJI O3 Lite, DJI O4

To keep the build light and responsive, pair this frame with 1003 micro motors, a standard 25.5x25.5mm whoop AIO flight controller, and a 2S LiPo battery.
