8mm Gold-Plated Cross-Cut Banana Bullet Connector

A single 8 mm gold-plated banana (bullet) connector with a cross-cut contact, for high-current battery, ESC and motor leads on large multirotors, agricultural drones and heavy-lift builds. Choose the male plug or the female socket; a complete joint needs one of each.

Key features

• 8 mm contact: a step up from 4 mm and 6 mm bullets for leads that carry heavy current
• Cross-cut pin: the slotted contact springs against the socket wall, giving a larger contact area and a firmer grip than a plain 4 mm banana
• 24K gold plating: over a copper body, resisting corrosion and keeping contact resistance low
• Solder cup: the tail slot takes the wire for straightforward soldering
• Sold singly: male and female are separate options, so you can order exactly the mix a repair needs

Fit the female socket on the battery or power-supply side so the live contact stays shrouded, size the wire to the current your pack and ESC carry, and cover every soldered joint with heat shrink.
