Turnigy 9XR PRO 24-Channel Programmable Radio Transmitter

The Turnigy 9XR PRO is a programmable computer radio running the ARM version of the open-source er9x firmware, with a JR-style module bay at the back. It ships without an RF module, so you add the JR-format transmitter module for the link you fly, and it suits pilots who run fixed wings, helicopters and multirotors from one handset and want deep, hands-on mixing.

Key features

• ARM er9x firmware with eePskye computer editor and simulator support
• Up to 24 channels and 48 free mixes, with expo, triple rates and curves
• Built-in telemetry display, plus voice alerts through a 1/2 W audio amplifier
• Micro SD card storage for models, telemetry logs, custom sound files and firmware updates
• Ball-bearing gimbals and tactile switches

Specifications

• Channels: up to 24
• Display: 128 x 64 LCD with dimmable backlight
• Model types: Heli, Acro, Glider, custom
• Model memory: 30+ models
• Stick modes: 1, 2, 3 and 4
• Encoder: PPM / PCM
• Module interface: JR-compatible bay
• Simulator interface: JR and Futaba compatible
• Battery compartment: 112 x 44 x 27 mm
• Weight: 723 g without battery and RF module

Budget for an RF module and a transmitter battery that fits the 112 x 44 x 27 mm compartment, as neither is in the box. Telemetry appears on screen only when the module and receiver you pair with it pass data back.
