ReadyToSky Titan 775 10-Turn Brushed Motor, 16.8V (5675 Type)

A 775-size brushed motor with a 10-turn winding for 1/10-scale off-road trucks that need a big can and plenty of torque. It is rated to 16.8 V, the full-charge voltage of a 4S LiPo, and suits high-load trail running, climbing and bashing where smaller 540 and 550 motors overheat under sustained load.

Key features

• 10-turn winding sits at the high-RPM, high-power end compared with higher-turn 775 motors
• Large 46.4 x 67 mm steel can for torque and heat capacity
• Heavy-duty 5 mm shaft, 13.5 mm long
• Rated to 16.8 V for 4S LiPo setups

Specifications

• Motor type: Brushed, 775 size
• Winding: 10 turns
• Max voltage: 16.8 V
• Can diameter: 46.4 mm
• Can length: 67 mm
• Shaft: 5 mm diameter, 13.5 mm long
• Scale: 1/10

Before ordering, confirm your chassis has a 775 motor mount and use a pinion with a 5 mm bore; 540 and 550 mounts and 3.175 mm pinions will not fit. Run it with a brushed ESC rated for 4S.
