DYS Samguk Shu 2306 Brushless Motor
SKU SAMGUK-SHU-2306-1750KV
KV: 1750KV
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The DYS Samguk Shu 2306 is an affordable 5-inch motor from DYS's Samguk series for racing, freestyle and trainer quads. It comes in two windings: 1750KV for 6S builds and 2500KV for 4S builds.
Key features
23 x 6 mm stator in a 28.5 x 17 mm motor body
M5 prop shaft for standard 5-inch props
About 33.6 g per motor, so a set of four weighs about 134 g
1750KV: rated for 4-6S, 40 A peak and 750 W
2500KV: rated for 3-4S, 44.1 A peak and up to 1060 g of thrust
Supplied as the CW version
Specifications
Stator: 23 x 6 mm (2306)
KV: 1750KV or 2500KV
Input: 4-6S LiPo (1750KV), 3-4S LiPo (2500KV)
Shaft: M5
Motor size: 28.5 x 17 mm
Weight: 33.6 g
Max current: 40 A (1750KV), 44.1 A (2500KV)
Max output: 750 W (1750KV), 1060 g thrust (2500KV)
Match the winding to your battery: the 1750KV feels soft on 4S with 5-inch props, and the 2500KV is not rated for 6S.
| Stator Size | 2306 |
|---|---|
| Stator Diameter | 23mm |
| Stator Height | 6mm |
| KV | 1750 KV, 2500 KV |
| Prop Mount | M5 |
| Shaft | 5mm |
| Input Voltage | 3–6S |
| Weight | 33.6 g |
| Brand | DYS |
| Made in India | No |
